Pyrometer Mikro PV 11
Intensity comparison pyrometer (successor to the filament pyrometer) for highly accurate temperature control in a measuring range from +700 °C to +3500 °C on small and very small objects from 0.1 mm. The Micro PV 11 is used in many areas of industrial research and production, by universities and research institutes for measuring filaments, smallest metal and ceramic samples and in absorption spectrometers.

Pyrometer Mikro PV 11

    • Measuring range 700 to 3000 °C
    • Large field of view for recognition of the object to be measured
    • Sharp contour image of the object to be measured
    • Extremely high optical resolution (objects of 1 mm can be measured at a distance of 5 m)
    • Measurement of very small objects from 0.1 mm
    • Very high measuring accuracy due to the measuring principle and the measuring wavelength
    • Very low influence of the emissivity
  • Version Mikro PV 11 AF 1
    Measuring range 700 - 3000 °C
    Focal distance 1 m - ∞
    Shape of the measurement area round
    Measuring principle one-colour
    Sighting option Through-the-lens-sighting
